Applicable Scenarios: pharmaceutical cold-storage warehouses, cool-storage warehouses, cold-chain logistics facilities, seed banks, electronics storage warehouses, and laboratories.
| Parameter | LTDW-90 | LTDW-138 | LTDW-150 | LTDW-7S | LTDW-10S | LTDW-15S | LTDW-20S |
| Power Supply | 220V-/50Hz | 220V-/50Hz | 220V-/50Hz | 380V 3N-/50H | 380V 3N-/50Hz | 380V 3N-/50Hz | 380V 3N-/50Hz |
| Dehumidification Capacity | 90L/D | 138L/D | 150L/D | 7kg/h | 10kg/h | 15kg/h | 20kg/h |
| Dehumidification Capacity Test Condition | 30℃ RH80% | 30℃ RH80% | 30℃ RH80% | 30℃ RH80% | 30℃ RH80% | 30℃ RH80% | 30℃ RH80% |
| Adjustable Humidity Range | 10%-90% | 10%-90% | 10%-90% | 10%-90% | 10%-90% | 10%-90% | 10%-90% |
| Applicable Temperature | 0-38℃ | 0-38℃ | 0-38℃ | 0-38℃ | 0-38℃ | 0-38℃ | 0-38℃ |
| Power | 1667W | 1917W | 2300W | 3.2KW | 4.8KW | 7.6KW | 11KW |
| Drainage Method | External hose drainage | External hose drainage | External hose drainage | External hose drainage | External hose drainage | External hose drainage | External hose drainage |
| Process Airflow | 800 m³/h | 1000 m³/h | 1200 m³/h | 1600 m³/h | 2400 m³/h | 3500 m³/h | 5000 m³/h |
| Air Filter | Primary Filter | Primary Filter | Primary Filter | Primary Filter | Primary Filter | Primary Filter | Primary Filter |
| Refrigerant | R22 | R22 | R22 | R22 | R22 | R22 | R22 |
| Waterproof Rating | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 |
| Current | 7.5A | 9.2A | 10.2A | 5A | 7.5A | 12A | 17.5A |
| Unit Dimensions (L×W×H) | 480 × 415 × 960 mm | 480 × 415 × 1060 mm | 600 × 500 × 995 mm | 610 × 400 × 1585 mm | 780 × 470 × 1690 mm | 1200 × 520 × 1750 mm | 1200 × 520 × 1750 mm |
| Weight | 43.5 kg | 49 kg | 53 kg | 75 kg | 128 kg | 186 kg | 220 kg |
A technology-based enterprise dedicated to air quality research and professional manufacturing of efficient and energy-saving ventilation equipment
