Applicable Scenarios: wine cellars, electronics workshops, museums, equipment rooms (server rooms), and laboratories.
| Model | LTCS-06 | LTCS-10 | LTCS-13 |
| Temperature Control & Measurement Range | 5-35℃±2℃ | 5-35℃±2℃ | 5-35℃±2℃ |
| Humidity Control & Measurement Range | 30-95%±5% | 30-95%±5% | 30-95%±5% |
| Cooling Capacity | 3.5KW | 5.1KW | 7.5KW |
| Heating Capacity | 2KW | 2KW | 3.6KW |
| Dehumidification Capacity | 2.0Kg/h | 3.5Kg/h | 5.5kg/h |
| Humidification Capacity | 1.5Kg/h | 3Kg/h | 3Kg/h |
| Circulation Airflow | 600m³/h | 1000m³/h | 1250m³/h |
| Unit Noise | ≤45dB | ≤45dB | ≤50dB |
| Power Supply | 220V/50Hz | 220V/50Hz | 220V/50Hz |
| Maximum Input Power | 3.6KW | 4.25KW | 6.1KW |
| Maximum Input Current | 16A | 19.5A | 28A |
| Compressor Input Power | 1.25KW | 1.38KW | 2.2KW |
| External Static Pressure | 70Pa | 70Pa | 100Pa |
| Air Port Size | φ180mm | φ200mm | φ200mm |
| Air Filter | Primary Filter | Primary Filter | Primary Filter |
| Control Method | Intelligent temp. & humidity control panel | Intelligent temp. & humidity control panel | Intelligent temp. & humidity control panel |
| Indoor Unit Dimensions (L×W×H) | 940 × 640 × 370 mm | 940 × 640 × 370 mm | 940 × 640 × 370 mm |
| Outdoor Unit Dimensions (L×W×H) | 812 × 256 × 540 mm | 850 × 310 × 610 mm | 920 × 340 × 700 mm |
