Applicable Scenarios: laboratories, museums, archives, equipment rooms (server rooms), production workshops, warehouses, and other places with environmental and humidity requirements.
| Model | Cooling Capacity | Heating Capacity | Humidification Capacity | Humidification Power | Compressor Power | Airflow | Unit ESP | Total Power | Power Supply | Indoor Unit Dimensions | Indoor Unit Weight | Outdoor Unit Dimensions | Outdoor Unit Weight |
| LTHF-5Q | 5.2kW | 3ky | 2kg/h | 1.5kW | 1*1.5 kW | 1000m³/h | 80pa | 5.25kW | 220V/50Hz | 620*580*1750mm | 120kg | 950*400*835mm | 60kg |
| LTHF-8Q | 8.2kW | 5kW | 4kg/h | 3kW | 1*2.55 kW | 1500m³/h | 80pa | 11.1kW | 380V/50Hz | 800*580*1900mm | 160kg | 735*635*795mm | 75kg |
| LTHF-9.5Q | 9.5kW | 6kW | 4kg/h | 3kW | 1*3.1 kW | 2500m³/h | 80pa | 12.8kW | 380V/50Hz | 800*580*1900mm | 180kg | 735*635*795mm | 75kg |
| LTHF-15Q | 14.9kW | 9kW | 4kg/h | 3kW | 1*4.1 kW | 3200m³/h | 90pa | 16.9kW | 380V/50Hz | 800*580*1900mm | 200kg | 835*740*950mm | 85kg |
| LTHF-20Q | 20kw | 9kW | 4kg/h | 3kW | 1*6 kW | 4300m³/h | 90pa | 20kW | 380V/50Hz | 1195*580*1900mm | 240kg | 885*785*1155mm | 120kg |
| LTHF-25Q | 25.5kW | 12kW | 6kg/h | 4.5kW | 1*7.5 kW | 5600m³/h | 200pa | 26.05kW | 380V/50Hz | 1300*740*2050mm | 300kg | 955*820*1155mm | 140kg |
| LTHF-30Q | 30kW | 15kW | 6kg/h | 4.5kW | 2*4.5 kW | 6800m³/h | 250pa | 31kW | 380V/50Hz | 1300*740*2050mm | 330kg | 835*740*950mm | 2*85kg |
| LTHF-40Q | 40kW | 21kW | 8kg/h | 6kW | 2*5.8kW | 8000m³/h | 300pa | 41.4kW | 380V/50Hz | 1550*740*2250mm | 350kg | 885*785*1155mm | 2*120kg |
| LTHF-52Q | 52.8kW | 27kW | 8kg/h | 6kW | 2*7.55kW | 10000m³/h | 300pa | 51.4kW | 380V/50Hz | 1650*740*2250mm | 400kg | 955*820*1155mm | 2*140kg |
| LTHF-62Q | 62kW | 36kW | 10kg/h | 7.5kW | 2*9kW | 12000m³/h | 300pa | 66kW | 380V/50Hz | 1850*1050*2350mm | 500kg | 955*860*1255mm | 2*170kg |
A technology-based enterprise dedicated to air quality research and professional manufacturing of efficient and energy-saving ventilation equipment
